P-2100H Ultra-high Pressure 2,800 Bar, Aluminium Bodied

The P-2100H Ultra-high Pressure 2,800 Bar Working Pressure, Aluminium Bodied Manual Hand Pump is a single acting, two speed, two way valve design that can be used for bolt tensioning, bearing removal and high pressure testing.

Ease of Operation

The pump has a low handle effort for ease of operation.

Ease of Handling

They have large, easy to grip external pressure release knobs.

Proven Performer

The pump is a robustly built industry proven performer.

Optional HP Gauges and Adaptors

Durapac also offer optional high pressure gauges and a gauge adaptor to suit the P-2100H, 2,800 bar hand pump.

2,800 Bar Working Pressure

Factory set to 2,800 bar working pressure. Other lower pressure settings are also available.

Safety Valve

The pump features a factory set safety pressure relief valve.
Model Number Operation Used with Cylinder Valve Type Pressure Rating (bar) 1st Stage Pressure Rating (bar) 2nd StageUsable Oil Capacity (cc) Oil Volumes per Stroke (cc) 1st Stage Oil Volumes per Stroke (cc) 2nd StageOil Port Thread Max. Handle Effort (kg) Weight with Oil (kg)
P-2100H Two Speed S/A 2 Way 28.02,8001,00013.00.73/4"-16UNF 406.9

P-2100H Cylinder Capacity v Pump Handle Strokes

Cylinder Capacity (ton) 510152025305075100150200250
P-2100H - 1st Pressure Stage - Movement* (mm)
P-2100H - 2nd Pressure Stage - Movement* (mm)1.0 0.4 0.3 0.2 0.2 0.2 0.1-----
* mm of movement for each stroke of the pump handle
- not recommended
