PDM1724-Diesel Driven Power Units

The PDM1724-Diesel Driven Power Unit is suitable for heavy duty applications in the field and can deliver a minimum flow of 38 Lpm at 138 bar pressure. It is specifically designed to operate a wide variety of hydraulic tools such as saws, drills and paving breakers for construction and demolition tasks.

pdm1724

Flow Combine Valve

The flow combine valve gives the ability to choose between operating 2 x 19 Lpm circuits or 1 x 38 Lpm circuit.

Individual Directional Control

Individual directional ON/OFF control valves.

KOHLER Diesel Motor

Reliable, air cooled diesel 17 HP KOHLER KD77-2® Motor.

Throttle Control

There is a throttle control lever for manual flow adjustment.

Shutdown Protection

Shutdown protection on high temperature and low oil pressure.

12 V Battery

The unit comes complete with a 12 volt battery, 12 volt /10 amp power outlets and a 12 volt electric start/stop control panel.
pdm1724
INSTRUCTIONS
SPECIFICATIONS
CATALOGUE
Model NumberHP rpm Maximum Pressure Rating (bar) Flow Rate (Lpm) Combine OFFFlow Rate (Lpm) Combine ONUsable Oil Capacity (L) Oil Port ThreadApprox. Dry Weight (kg)
PDM1724173,6001382 x 1938197/8"-14 UNF240
