Low Pressure Unloading Valve
The power unit has a built in low pressure unloading valve.
Safety Pressure
The power unit has a 700 bar safety pressure relief valve.
Perfect Power
The power unit is driven by a 3.0 kW, 415 Volt / 50 Hz, 3 phase electric motor.
Medium to Large Tonnage
Ideal for operating medium to large tonnage cylinders and systems.
Remote Pendant
The unit includes a 4 metre remote pendant to jog the electric motor ON / OFF.
Adjustable Pressure
An externally adjustable pressure relief valve is included.
| Model No. | 1st Stage Flow Rate (Lpm) | 2nd Stage Flow Rate (Lpm) | 1st Stage Pressure Rating (bar) | 2nd Stage Pressure Rating (bar) | Motor kW | Voltage (50 Hz) | Amps | Remote Pendant Function 4 mtr | Valve Type (3/8"-NPTF Ports) | Usable Oil Cap. (L) | Approx. Dry Weight (kg) | Approx. Dimensions (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PEM3024 | 10.5 | 2.1 | 100 | 700 | 3 | 415 | 6.3 | ON/OFF JOG SWITCH* | 4w/3p Manual | 20 | 71 | 320 W x 450 L x 560 H |
To order with remote pendant; add "R" to the end of the model number.
^ Standard supply includes roll frame and 63mm diameter pressure gauge.
Piston Rod Speed v Cylinder Capacity (30 Series)
| Pressure Stage | Flow (Lpm) | 10 Ton (mm per second) | 15 Ton (mm per second) | 20 Ton (mm per second) | 25 Ton (mm per second) | 30 Ton (mm per second) | 50 Ton (mm per second) | 75 Ton (mm per second) | 100 Ton (mm per second) | 150 Ton (mm per second) | 200 Ton (mm per second) | 250 Ton (mm per second) | 300 Ton (mm per second) | 400 Ton (mm per second) | 500 Ton (mm per second) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1st | 10.5 | 121 | 86 | 61 | 53 | 42 | 23 | 17 | 13 | 8.8 | 6.6 | 4.8 | 3.8 | 3.1 | 2.4 |
| 2nd | 2.1 | 24 | 17 | 12 | 11 | 8.3 | 4.5 | 3.4 | 2.6 | 1.8 | 1.3 | 1 | 0.8 | 0.6 | 0.5 |
