RHD-Series D/A, Hollow Piston Rod

The RHD-Series is a Double Acting, Hollow Piston Rod Cylinder. The hollow piston allows for a rod or cable to be inserted through the entire body length, while the double acting design improves speed of operation when longer stroke cylinders are required. They can be used in tensioning, load testing, bush extracting, and maintenance applications.

RHD-10010

RHD Cross Section

TSH-100

RHD-7513 with Handles

RHD_group_image

Steel Base Plate

The steel base plate protects the base and is removable to allow the use of threaded mounting holes.

Safety Valve

The safety pressure relief valve protects the cylinder from intensification due to a checked hydraulic return coupling.

Threaded Fit Smooth Saddle

The threaded fit smooth saddle prevents piston rod damage. Optional TSH threaded saddles are also available.

Bronze Overlay

The piston bearing area is bronze overlaid to reduce side load induced damage and extend cylinder life.

Hard Chrome Plated Piston Rod

A hard chrome plated piston rod maximises corrosion-resistance and cylinder life.

Gland Nut

Low friction coating on the gland nut withstands full dead end loading.

RHD_group_image

Model Number	Cylinder Capacity ton*	Cylinder Capacity Advance kN	Cylinder Capacity Retract kN	Stroke (mm)	Cylinder Effective Area Advance (cm²)	Cylinder Effective Area Retract (cm²)	Oil Capacity Advance (cm³)	Oil Capacity Retract (cm³)	Collapsed Height (mm)	Extended Height (mm)	Outside Diameter (mm)	Cylinder Bore Diameter (mm)	Piston Rod Diameter (mm)	Base to Advance Port (mm)	Top to Return Port(mm)	Standard Saddle Diameter (mm)	Saddle Protrusion from Piston Rod (mm)	Piston Rod Internal Thread	Piston Rod Thread Length (mm)	Collar Thread	Collar Thread Length (mm)	Centre Hole Diameter (mm)	Weight (kg)	Base Mounting Holes Bolt Circle Diameter (mm)	Base Mounting Holes Thread	Base Mounting Holes Thread Depth (mm)	Model Number	Optional Threaded Saddles Model Number	Handle Type
RHD-307	30	326	213	178	46.6	30.4	830	541	330	508	114	88.9	63.5	25	60	63	9	1-13/16"-16UN	22	4-1/2"-12UN	42	33.3	21	92.2	3/8"-16UNC	15.7	RHD-307	TSH-30	♥
RHD-3010	30	326	213	258	46.6	30.4	1203	784	431	689	114	88.9	63.5	25	60	63	9	1-13/16"-16UN	22	4-1/2"-12UN	42	33.3	27	92.2	3/8"-16UNC	15.7	RHD-3010	TSH-30	♥
RHD-603	60	576	377	94	82.3	53.8	732	479	247	336	159	123.9	92.2	31	66	91	12	2-3/4"-16UN	19	6-1/4"-12UN	48	54.1	28	130	1/2"-13UNC	14	RHD-603	TSH-60	♥
RHD-606	60	576	377	166	82.3	53.8	1366	893	323	489	159	123.9	92.2	31	66	91	12	2-3/4"-16UN	19	6-1/4"-12UN	48	54.1	35	130	1/2"-13UNC	14	RHD-606	TSH-60	♥
RHD-6010	60	576	377	257	82.3	53.8	2115	1382	438	695	159	123.9	92.2	31	66	91	12	2-3/4"-16UN	19	6-1/4"-12UN	48	54.1	45	130	1/2"-13UNC	14	RHD-6010	TSH-60	♥
RHD-1001	100	931	612	38	133	87.4	506	332	165	203	212	165.1	127	38	44	126	12	4"-16UN	25	-	-	79.5	33	177.8	5/8"-11UNC	19	RHD-1001	TSH-100	♥
RHD-1003	100	931	612	76	133	87.4	1012	664	254	330	212	165.1	127	38	85	126	12	4"-16UN	25	8-3/8"-12UN	60	79.5	61	177.8	5/8"-11UNC	19	RHD-1003	TSH-100	♥
RHD-1006	100	931	612	153	133	87.4	2037	1337	342	495	212	165.1	127	38	85	126	12	4"-16UN	25	8-3/8"-12UN	60	79.5	79	177.8	5/8"-11UNC	19	RHD-1006	TSH-100	♥
RHD-10010	100	931	612	257	133	87.4	3421	2245	460	717	212	165.1	127	38	85	126	12	4"-16UN	25	8-3/8"-12UN	60	79.5	106	177.8	5/8"-11UNC	19	RHD-10010	TSH-100	♥
RHD-1508	150	1429	718	203	204.1	102.6	4142	2082	349	552	247	190.5	152.4	38	60	127	4	4-1/4"-12UN	25	-	-	79.5	111	214	5/8"-11UNC	15	RHD-1508	-	♥

* Nominal Cylinder Capacity in ton - see kN values for actual capacity
HANDLE TYPES: ♣ WELDED ♦ EYEBOLT ♥ REMOVABLE STRAP HANDLE ♠ THREAD

RHD-Series Seal Kits

Seal Kit to Suit	Part Number
RHD 30 TON SERIES	ZAM1043
RHD 60 TON SERIES	ZAM1044
RHD 100 TON SERIES	ZAM1041
RHD 150 TON SERIES	ZAM1042
