100 Tonne Rated & Certified
The DJS-Series Jack Stands are rated and certified to 100 tonne, and comply with AS/NZS 2538:2004 standard for vehicle support stands.
Ease of Use
Fork tine pockets and shackle lifting points are provided for ease of use and manoeuvring. A standard Euro style pallet jack can also be used for transport of the stand.
Compatible
Standard SDL extensions, load and swivel load caps may be used.
Dedicated Stands
They can be permanently joined via continuous tine pockets to produce dedicated stands for particular vehicles or applications.
3 Way / 3 Position Control Valve
3 way, 2 position control valve releases air from cylinder.
Manoeuvrability
An optional spring loaded caster assembly is available to assist in final positioning of the stand.
| Model Number | Load Capacity (tonne) | Min. Height (mm) | Max. Height (mm) | Base WxL (mm) | Air Pressure Rating (bar) | Max. Rated Height (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| DJS-650 | 100 | 650 | 900 | 600x600 | 7 | 1,100 | 274 |
| DJS-800 | 100 | 800 | 1,200 | 600x600 | 7 | 1,500 | 323 |
| DJS-1000 | 100 | 1,000 | 1,400 | 600x600 | 7 | 1,700 | 370 |
Optional Extensions & Load Caps to suit DJS
| Model Number | Description | Height (mm) | Diameter (mm) | Spigot Depth (mm) | Spigot Diameter (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| SDE150-150 | 150 mm Extension | 150 | 126 | 60 | 50 | 7 |
| SDE150-200 | 200 mm Extension | 200 | 126 | 60 | 50 | 9 |
| SDE150-250 | 250 mm Extension | 250 | 126 | 60 | 50 | 11 |
| SDE150-300 | 300 mm Extension | 300 | 126 | 60 | 50 | 13 |
| SDLC-150 | Serrated Steel Load Cap * | 22 | 126 | 60 | 50 | 3 |
| SDS-150/200N | Serrated Tilt Saddle | 54 | 126 | 60 | 50 | 5 |
* Supplied as standard
- Consult Durapac
